Contact usBrake Drums
Fits RENAULT CLIO IV (BH_) 1.5 dCi 110
(2016)
Categories
Important compatibility info
| Manufacturer | RENAULT |
| Placement on Vehicle | Rear Axle |
| Model | CLIO TWINGO |
| Additional Information 2 | without ABS sensor ring, with wheel bearing |
| Br. Drum outer diameter | 234 mm |
| Number of Holes | 4 |
| Bolt Hole Circle Diameter | 100 mm |
| Centering Diameter | 52 mm |
| Inner Brake Drum Height | 47 mm |
| Total Br. Drum Height | 76 mm |
| Inner Brake Drum Diameter | 203 mm |
| Type | Brake Drum |
| Function | Brake Drum |
£49.33
Important compatibility info
| Placement on Vehicle | Rear Axle |
| Additional Information 2 | with ABS sensor ring, with wheel bearing |
| Number of Holes | 4 |
| Bolt Hole Circle Diameter | 100 mm |
| Inner Brake Drum Height | 46 mm |
| Total Br. Drum Height | 76 mm |
| Br. Drum outer diameter | 234 mm |
| Inner Brake Drum Diameter | 203 mm |
| Type | Brake Drum |
| Function | Brake Drum |
£52.97
Important compatibility info
| Inner Brake Drum Diameter | 229 mm |
| Total Br. Drum Height | 89 mm |
| Type | Brake Drum |
| Function | Brake Drum |
| Replaces | 253934 |
| Additional Information 2 | with wheel bearing, with ABS sensor ring |
| Number of Holes | 4 |
| Max.skimmed drum measure | 229.5 mm |
| Inner Brake Drum Height | 52 mm |
| Br. Drum outer diameter | 261 mm |
£58.37
Important compatibility info
| Centering Diameter | 61.9 mm |
| Width | 50 mm |
| Weight | 8.35 kg |
| Max.skimmed drum measure | 228.5 mm |
| Outer diameter | 261 mm |
| Thickness | 74 mm |
| Additional Information 2 | with wheel bearing, with ABS sensor ring |
| Inner diameter | 229 mm |
| Bolt Hole Circle Diameter | 100 mm |
| Placement on Vehicle | Rear Axle Left, Rear Axle Right |
| Rim Hole Number | 4 -Hole |
| Function | Brake Drum |
| Type | Brake Drum |
Additional Information
General Information
These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.
£131.54
Important compatibility info
| Function | Brake Drum |
| Type | Brake Drum |
| Placement on Vehicle | Rear Axle Left, Rear Axle Right |
| Width | 50 mm |
| Outer diameter | 261 mm |
| Thickness | 74.2 mm |
| Rim Hole Number | 4 -Hole |
| Max.skimmed drum measure | 228.5 mm |
| Weight | 8.35 kg |
| Centering Diameter | 61.9 mm |
| Bolt Hole Circle Diameter | 100 mm |
| Inner diameter | 228.6 mm |
| Additional Information 2 | with wheel bearing, with ABS sensor ring |
Additional Information
General Information
These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.
£131.54
What is a brake drum?
A brake drum is part of the rear brake system where the vehicle uses brake shoes rather than a disc and pad system. The brake drum is positioned over the brake shoes on the rear axle. When the brake cylinder pushes the brake shoes up against the inside of the brake drum it provides braking for the rear wheels.
What comes with a brake drum?
Brake drums are generally sold as a single item unless stated otherwise in the parts listing.
Brake drums can include the following items:
Wheel bearing
ABS sensor
How do I choose the correct brake drum?
Brake systems can vary between the same model of vehicle. With this in mind there are a number of different factors to consider when choosing correct replacements. We recommend reading any compatibility notes listed next to a part that is shown as correct for your vehicle.
Some of these compatibility notes can include:
Original manufacturer of the brake system
Diameter of the drum
Depth of the drum
Does vehicle have ABS
Vehicle manufacture date (this is not the date the vehicle was registered but the date it was made
VIN (chassis number) sequence (up to or after as specific number/letter
What brand of brake drum should I choose?
Brands such as Bosch and TRW manufacture brake system parts directly for the original vehicle manufacturer. These would be classed as premium brands. This is reflected in their cost.
There are high quality aftermarket brands such as Apec, Blue Print, Borg & Beck, Febi and Juratek that offer long warranty cover which shows the confidence they have in the quality of their products.
The brand you choose is likely down to your budget and the length of warranty provided. We’d recommend the brand with 2 or more years warranty cover.
How can I tell my brake drums needs replacing?
If you have any concerns about your brake system we would always recommend that you consult a qualified mechanic who will be able to diagnose any issues.
Here are some symptoms of a faulty or worn out brake drum:
Vibrations when braking
Scraping, grinding or squealing noise when braking
Poor braking performance
The parking brake does not work properly
Car pulls to one side while braking
