Fits CHEVROLET MATIZ (M200, M250) 0.8 LPG
(2005)
Categories
Important compatibility info
| Thread Measurement 1 | M12x1.5 |
| Thread Type | with right-hand thread, with internal thread |
| Function | Tie Rod End |
| Type | Tie Rod End |
£10.66
Important compatibility info
| Weight | 0.30 kg |
| Placement on Vehicle | Front Axle Left, Front Axle Right |
| Internal Thread Size | M12 x 1,5 |
| External Thread Size | M12 x 1,5 |
| Function | Tie Rod End |
| Spanner Size | 13 |
| Type | Tie Rod End |
| Length | 73 mm |
| Additional Information 2 | with crown nut |
| Replaces | ADG08712 |
Additional Information
General Information
These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.
£10.67
Important compatibility info
| Placement on Vehicle | Front Axle Left, Front Axle Right |
| Length | 73 mm |
| Colour | Silver |
| Function | Tie Rod End |
| Weight | 0.30 kg |
| Internal Thread Size | M12 x 1,5 |
| External Thread Size | M12 x 1,5 |
| Extra Description | ProKit |
| Type | Tie Rod End |
| Additional Information 2 | with crown nut |
Additional Information
General Information
These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.
£10.67
Important compatibility info
| Thread Size | M12x1,5 |
| Placement on Vehicle | Front Axle |
| Type | Tie Rod End |
| Function | Tie Rod End |
| Cone Size | 12.8 mm |
£10.99
Important compatibility info
| Thread Measurement 1 | M12x1.5 |
| Thread Type | with right-hand thread, with internal thread |
| Function | Tie Rod End |
| Type | Tie Rod End |
£11.05
Important compatibility info
| Thread Size | M12x1.5 |
| Cone Size | 12.5 mm |
| Thread Type | with right-hand thread |
| Function | Tie Rod End |
| Width | 40 mm |
| Height | 70 mm |
| Length | 98 mm |
| Type | Tie Rod End |
| Placement on Vehicle | Front Axle |
£12.02
Important compatibility info
| Additional Information 2 | with fastening material |
| Placement on Vehicle | Front Axle |
| Function | Tie Rod End |
| Extra Description | Premium Kit+ |
| Type | Tie Rod End |
| Cone Size | 12.5 mm |
| Length | 70 mm |
| Thread Measurement 1 | FM12X1,5R |
| Thread Measurement 2 | MM12X1,25R |
£14.50
Important compatibility info
| Thread Measurement 2 | M12x1.5 |
| Axle Joint Length | 252 mm |
| Function | Inner Tie Rod |
| Width | 36 mm |
| Height | 36 mm |
| Length | 266 mm |
| Type | Inner Tie Rod |
| Placement on Vehicle | Front Axle Left, Front Axle Right |
£17.68
Important compatibility info
| Axle Joint Thread Type | with right-hand thread, with external thread |
| Axle Joint Length | 266 mm |
| Length | 266 mm |
| Thread Measurement 2 | M12X1.5 |
| Thread Measurement 1 | M16X1.5 |
| Function | Inner Tie Rod |
| Type | Inner Tie Rod |
£18.76
Important compatibility info
| Axle Joint Thread Type | with right-hand thread, with external thread |
| Thread Measurement 2 | M12X1.5 |
| Length | 266 mm |
| Thread Measurement 1 | M16X1.5 |
| Function | Inner Tie Rod |
| Axle Joint Length | 266 mm |
| Type | Inner Tie Rod |
£19.95
Important compatibility info
| Placement on Vehicle | Front Axle |
| Thread Measurement 2 | M16x1.5 |
| Thread Measurement 1 | M12x1.5 |
| Function | Inner Tie Rod |
| Axle Joint Length | 252 mm |
| Type | Inner Tie Rod |
£20.10
Important compatibility info
| Function | Steering Lock |
| Weight | 0.41 kg |
| Number of Connectors / Ports | 4 |
| Operating Mode | Electric |
| Type | Steering Lock |
| Lock System | with two keys, with lock barrel |
| Additional Information 2 | with switch, with bolts/screws |
Additional Information
General Information
These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.
£77.89
Important compatibility info
| Additional Information 2 | with switch |
| Weight | 0.605 kg |
| Number of Connectors / Ports | 7 |
| Function | Steering Lock |
| Lock System | without lock barrel |
| Type | Steering Lock |
Additional Information
General Information
These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.
£122.41
What is a steering tie rod and tie rod end?
Steering tie rods and tie rod ends are part of the steering rack system. As the wheel moves up and down over uneven road surfaces the articulated joint in the rod allows that movement so that the rod does not become damaged.
The tie rod end is fitted to the end of the tie rod. The tie rod end provides 2 main functions. It provides adjustment to the wheel being steered so that its track or direction of the wheel can be aligned. The ball joint end of the tie rod end provide articulation so when the wheel is being steered it can move accordingly.
These parts are available in different sets as follows:
Single tie rod
Single tie rod end
Single tie rod and tie end kit
Single tie rod and tie end kit with boot kit
How do I choose the correct tie rods and tie rod ends?
Some vehicle manufacturers use different companies (brands) to manufacture the steering system for their vehicles. If this is the case the replacement tie rods and tie rod ends need to match the brand of the steering system.
There can be other factors to note when looking for replacement steering system parts which are listed below:
Electric or hydraulic steering gear
Length of the rod or diameter of the ball cone mount on the tie end
Manufacturer of the steering rack (i.e. TRW, ZF etc)
If you need the left hand or right hand side
Vehicle manufacture date (this is not the date the vehicle was registered but the date it was made
VIN (chassis number) sequence (up to or after as specific number/letter
What brand of tie rods and tie rod ends should I choose?
There are many aftermarket makers of steering tie rods and tie rod ends so the choice of which brand to order can be tricky. Budget is often one of the main criteria when choosing replacement parts. Brands such as Apec, Blue Print, Febi and FAG offer long warranties and offer parts at a low price point too. These brands and others like them that offer long warranties means you can be confident in their parts and not spend a small fortune either.
How can I tell my tie rods or tie rod end need replacing?
The steering system is safety critical and is tested as part of the UK MOT. These parts work under stress and are situated in an exposed part of the vehicle. Time, damage and wear and tear will cause these parts to fail.
We would always recommend that you have your vehicle inspected by a qualified mechanic if you have any safety or performance concerns with your steering system.
Here are some of the symptoms of failing tie rods and tie rod ends:
Creaking or some other abnormal sound when steering
Tyres are wearing unevenly
The vehicle pulls to one side. It's hard to maintain a straight line
Vibration while driving more pronounced through the steering wheel
Steering feels loose or is not responsive
The rubber cover on the tie rod end is split
