Testing / Diagnostic
Tools Sub-Categories
Important compatibility info
Depth | 50 mm |
Temperature range | -20 - 55 °C |
Temperature range from | -20 °C |
Temperature range to | 55 °C |
Extra Description | FSA 050 |
Additional Information
- Standalone tester: Get fast results with insulation and high-voltage testing for electric and hybrid drive
- Combines as a test module with FSA 500: Enhance functionality and output to comprehensively document measurement test results
- Compact (220 x 110 x 65 mm): Handy size for efficient working
- Lightweight (0.8 kg): The mobile solution around the workshop
- Bluetooth interface: Ultimate convenience – wirelessly transmit test results to workshop PC or FSA series
- Complete with storage case, two measuring cables, high-voltage probe, CD/DVD CompacSoft[plus] and Bluetooth USB stick: It’s the economical package for testing electrical drive systems
- Wireless connectivity: Conntect with Bosch Connected Repair or other workshop networks to help you work more efficiently
- High-voltage analysis: up to 600 V (TRMS)
- Insulation analysis:until 200 G Ω
- Insulation resistance: 50 - 100 - 250 - 500 - 1 000 V
- Test voltages: 1 mA
- Test current Measurement modes: t, PI, DAR
- Resistance measurement: 0.01 - 1 000 kOhm
- Continuity testing: 0.01 - 99.9 Ohm with test current 20 mA / 205 mA
- Capacitance measurement: 100 picofarad - 10 microfarad
- Data transmission: Bluetooth class I (up to 30 m range)
- Power supply: Batteries 5x IEC LR6 (AA)
- Operating temperature range -20 - 55 degree(C)
- Weight: 0.8 kg
- Dimensions: 220 x 92 x 50 mm
Important compatibility info
Title | Bosch TPA 300 - Programming Tool for TPMS |
Additional Information
- Vehicle coverage of over 95%
- Reading & cloning of wide range of OE-sensors
- Programming a broad range of universal sensors
- Relearn procedures for many of vehicles
- Intuitive, full-color display with easy vehicle lookup by make, model and year
- Supports the majority of OE and aftermarket programmable sensors for passenger car and LCV vehicles
- New features, vehicles and sensor coverage added regularly
- Approximately 300 activations per full charge
- Includes 3 years of free software updates
Important compatibility info
Additional Information
- Supports 120 A DC Continuous Output (AC120 V - 240 V, 25 degree Celcius)
- Supports Flooded/AGM/EFB/GEL/Lithium (LFP) Batteries
- 12 V Lead Acid Battery Charge. Charging Diagnosis / 12 V Lithium Battery Charge, Wake Up
- Interface available in 26 languages
- Maximum power output: up to 1750 W
- Flexible operation modes to fulfill customer needs
- Desk, floor or wall operations possible
- Fits underneath a car in show room
- Easy to use large 4 colour backlight LCD display including wall mount mode
- Easy access to BAT 6120 Help Center web page through QR code displayed on the screen
- Max. Charge current intensity 12V: 120 A
- Length of the charging cable: 3 m (twin cable)
- Cross-section charging cable: 25 mm sq.
- Power input :120 - 240 V AC
- Weight (without charging and power cable): 8.5 kg
- Charging characteristic: up to 120 Amperes continuous. Battery types: UNI, WET, EFB, AGM, VRLA/GEL, LFP (LiFePO4)
- Backup mode: 12.0 V - 13.2 V adjustable, default 12.6 V / 10 A - 30 A adjustable power limit, default 20 A
- Floating-mode operation: 12.0 V - 13.2 V adjustable, default 13.5 V
- Max. 120 A continuous current
- Function temperature range: 0 – 40 degree(C)
- Main voltage: 220 - 240 V, 50/60 Hz
- Battery nominal voltage: 12 V
- Protection type (DIN 40050): IP 20 D
- Dimensions (W x H x D): 329 x 116 x 433 mm
Important compatibility info
Additional Information
- Micro-load test procedure: Produces fast and reliable measurement results
- Large LCD screen: For clear, legible results which can be referenced quickly
- EN, EN2, DIN, SAE, IEC, JIS and MCA testing norms: For versatile testing of 6 V and 12 V batteries, and the 12 V and 24 V starter charging systems
- Guided menus in 25 languages with 3-button operation: Easy and intuitive to use
- Integrated printer presenting state of health and state of charge percentage: Provides the customer with clear and easy to understand graphical printouts for their records
- 1.8 meter testing cable: For excellent coverage around the vehicle in the workshop
- Only 1100 g with robust housing: Provides easy handling and durability for daily use
- Detachable test clamps: For service or replacement
- Supports testing of starting and charging systems
- Battery nominal voltage: 6 V / 12 V
- Application: Passenger car, light commercial vehicle, motorcycle, marine
- Battery types: Lead-acid, EFB, Gel & AGM (flat and spiral)
- Test standards: EN, EN2, DIN, SAE, IEC, JIS, MCA
- Battery size (in acc. with CCA): 40 – 2000 A
- Printer: Integrated thermal printer
- Starting/charging system test 12 V / 24 V
- Number of Menu languages: 25 languages
- Dimensions (W x H x D): approx. 250 x 130 x 60mm
- Weight approx.: 1100 g
- Operating temperature: 0 – 40 degree(C)
Important compatibility info
Title | Bosch OBD Interface Module |
Additional Information
- Kit with LAN cable
- Writes sensor values into ECU of vehicle as integrated part of the process
- Writing sensor values can also be done using the ESI[tronic] – but the dongle is faster, since there is no typing required
- OBD Module simplifies the workflow significantly when it is needed (mainly Asian OEMs such as Toyota, Hyundai, Nissan), reduces manual data entry of long sensor codes
Important compatibility info
Function | Plug Sleeve, ignition system |
Type | Plug Sleeve, ignition system |
Important compatibility info
Title | Jump Lead Clips - 600A - Pair |
Additional Information
- Heavy-duty booster cable handles
- Fully insulated handles
- Rated up to 600 Amp
- Suitable for up to 35mm2 cable
