Hella 2SB980887-211 Rear Light Lamp

Technical Information

Instruction 2 - Regarding single or double function lamps wi th LEDs without flasher function In connection with these low powers, which are very differen t from bulb versions, there can be problems during operation on various traction vehicles because further lighting functi ons are detected by some traction vehicles. This is a vehicle comfort function which is not required by legislation and does not release drivers from their obligati on to see for themselves that the lighting equipment is working . Here, too, faulty diagnoses can be a result of the lower pow er levels involved (instrument panel in the driver cab indic ates a bulb failure although the function is working). The functional ability of these light failure checks can onl y be established by the vehicle manufacturer. Operation of the light with alternating current or pulsed di rect current is not permitted! The individual light functions may only be operated with a v ehicle fuse of max. 3A. In the case of onboard current limitation with the values sp ecified above by the onboard control unit an additional fuse for the lamp is not required.

• 1x Hella Cap (9HD980885-018)
