Workshop Tools

• Added Convenience: The Power Probe DM500MAX Automotive Multimeter Voltage Tester has automatic back light that adjusts to changing light conditions; Drop resistant protective rubber holster
• Measuring Voltage: Accurately and automatically determine both AC and DC voltage from 0.01mV-1000V with 600V cat IV and 100V Cat III safety rating for testing vehicle batteries or home appliances
• Testing Current: Correctly calibrate amperage for both AC and DC currents with auto-range metering from 0.01mA-10.00A; Determine whether or not an outlet is active or if solar cells function properly
• For All Electrical Testing: Power Probe digital multimeters don’t just measure voltage and amperage but also resistance, frequency, continuity, capacitance, and even temperature
• Multimeter kit includes a DM500MAX multimeter, drop resistant rubber housing with kickstand, magnetic strap, 2 test leads (1 black, 1 red), 2 alligator clip lead attachments (1 black, 1 red), a USB plug, K-type thermocouple, and 4 AA batteries

• Measurement Capabilities: True RMS AC/DC voltage up to 1000V
• DC current up to 30A
• resistance up to 60MΩ
• Automotive Diagnostics: Cranking voltage tests
• alternator charging system tests for 12V/24V
• Fuse Current Testing: Measures current through fuses without removal (2A to 80A)
• Frequency and Duty Cycle: Measures PWM signals up to 40kHz
• duty cycle range: 1%-99%
• Thermal Imaging: Integrated infrared temperature measurement for advanced diagnostics
• Display: 3.5” high-resolution TFT color LCD with customizable interfaces
• Power Source: Rechargeable lithium-ion battery
• Durability: 4-foot drop protection
• IP54 dust and water resistance
• Safety Ratings: CAT IV 600V
• CAT III 1000V certified
• Data Storage: On-device memory for saving multiple test results.

• 1x Gates Mounting Tools, timing belt (GAT4640T7)
• 1x Gates Mounting Tools, timing belt (GAT4840V4)
• 1x Gates Mounting Tools, timing belt (GAT4909)

• Measures current Flowing through fuses without removing the fuse (up to 80A)
• Fuse Voltage drop testing
• Guided automotive test mode
• AC/DC Voltage measurements up to 1000V
• Current measurements up to 30A
• Measures resistance, continuity and diode testing
• Frequency and duty cycle for PWM signals

• Measurement Capabilities: True RMS AC/DC voltage up to 1000V
• DC current up to 30A
• resistance up to 40.00MΩ
• Automotive-Specific Functions: Cranking voltage tests for 12V/24V starters
• alternator charging tests for normal/smart alternators
• Fuse Testing: Measures current through fuses without removal (2A to 80A)
• Frequency and Duty Cycle Measurement: Measures PWM signals up to 20.00kHz and duty cycles from 1%-99%
• Continuity and Diode Testing: Provides audible and visual feedback
• Display: 2.8” TFT color LCD with a user-friendly menu
• Power Supply: Powered by 3 AAA alkaline batteries
• Durability: Drop protection for up to 4 feet
• Safety Standards: CAT IV 600V
• CAT III 1000V rated
• Dimensions: 92.6mm x 205mm x 57.5mm
• weight: 588g
• Accessories: Includes 30A probe
• test leads
• fuse current probe set
• alligator clips.

General Information

These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Insulation Test with PI/DAR/Timed
• mA-selectable mode
• Auto bi-direction continuity Test
• Visual/acoustic compare function
• Auto AC/DC Voltage Test with LPF
• 1500 records of Store/Recall

• Measures AC Voltage(ACV)
• DC Voltage(DCV)
• Frequency
• Earth-bond Resistance(Continuity)
• Capacitance
• Insulation Resistance
• Features Auto-sense mode for automatic detection of ACV or DCV
• Insulation test range: 50V to 1000V with maximum resistance range up to 200GΩ
• Earth-bond resistance measurement range: 0.01Ω to 40.00kΩ
• Capacitance measurement range: 0.1nF to 10.00uF
• Bluetooth Low Energy(BLE) V5.0 for wireless data transfer
• Compliance with IEC/EN 61010-1 and IEC/EN 61557 standards
• IP40 rated for dust resistance
• operates up to an altitude of 2000m
• True RMS measurements
• automatic discharge function
• CAT IV 600V rated
• supports up to 1500 stored readings
• Auto power-off for battery preservation
• Dimensions: 96mm x 207mm x 54mm
• weight: 630g
• powered by 4 AA batteries.

General Information

These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.
